Product Overview

The Automotive Gasoline Engine Training Equipment consists of two parts:

1. A fixed stand for the electronically controlled gasoline engine assembly and its operating accessories.

2. A running detection control panel stand.

This equipment is suitable for teaching applications in:

Secondary and higher vocational/technical colleges.

General education colleges.

Automotive training institutions (for engine maintenance and repair training).

Core Features

1. Real Engine Simulation and Operation

The Automotive Gasoline Engine Training Equipment features a fully operational, electronically controlled gasoline engine that comprehensively demonstrates the structural components and operational processes of a modern engine. It supports essential functions—including starting, acceleration, and deceleration—under simulated real-world conditions, enabling hands-on training and diagnostic practice.

2. Modular Training Platform Design

The Automotive Gasoline Engine Training Equipment comprises two integrated components: a fixed stand containing the complete electronically controlled gasoline engine assembly with its operating accessories, and a dedicated control stand featuring the operation and detection panel. This modular configuration improves accessibility and optimizes workflow during practical training exercises.

3. High-Quality Circuit Panel with Visual Aids

A full-color UV flat-panel printed circuit diagram is integrated into the control panel, allowing trainees to visually match the schematic with the actual engine components. The panel consists of a 4mm thick, high-grade aluminum-plastic composite material that resists corrosion, impact, contamination, fire, and moisture. Featuring a special primer-coated surface for enhanced durability, the printed circuit diagram maintains long-term color vibrancy and fade resistance.

4. Integrated Electrical Signal Detection Terminals

The Automotive Gasoline Engine Training Equipment features specialized detection terminals for directly measuring electrical signals—including resistance, voltage, current, and frequency—from sensors, actuators, and the Engine Control Unit (ECU). This capability provides trainees with hands-on experience in analyzing system diagnostics and understanding control logic principles.

5. Comprehensive Instrumentation and Diagnostic Capability

The Automotive Gasoline Engine Training Equipment incorporates built-in automotive instruments – a fuel pressure gauge and vacuum pressure gauge – that display real-time engine parameter changes, including speed. It also features a diagnostic port compatible with both professional and universal automotive scanners, enabling engine electronic control system functions such as fault code reading/clearing and data stream analysis.

6. Robust and Mobile Construction

The Automotive Gasoline Engine Training Equipment features a welded steel base with rounded safety hand guards on the front and sides. A 20cm steel worktable is integrated for tool and instrument placement. The complete unit is finished with durable spray paint and includes lockable casters, providing stable, secure, and mobile operation during training demonstrations.

Technical Specifications

Product Name: Controlled Gasoline Engine Training Bench

Model: ZC-QCA01

Dimensions: 1500 × 1000 × 1700 mm

Power Supply: DC 12V

Fuel Type: 92# gasoline

Fuel Tank Capacity: 10 liters

Applicable Engine: Toyota Corolla 1ZR electronically controlled gasoline engine
